HYVZ SeriesSolid Insulated Automatic Vacuum Circuit Recloser isforged forthe purpose of maintaining the stability of electricity network. When emergencies occur, it can trip off the current and reclose the current in a set sequence until the fault is resolved, or the fault remains, it will open the circuit to protect the power system. The HYVZseries is applied in electricity distribution network of rated voltage 15kV, 27kV,38kV, rated current 630A or 800A, frequency 50Hz or 60Hz, featuring unibody solid encapsulation, premium quality firm and thick hydrophobic epoxy resin, reliable vacuum interrupter, robust base tank and stainless steel components, to guarantee outstanding performance in service.Perfect balance of price and performance offers a huge advantage for your budget. Product Advantage 1. Auto recloser it helps to quickly restore power after a temporary fault, reducing downtime and increasing productivity.. 2. Auto Vacuum Circuit recloser it can prevent damage to equipment by isolating the faulty section of the circuit and then automatically reconnecting it once the fault has been cleared.. 3. Auto Vacuum Circuit recloser it improves the reliability of the power supply by automatically attempting to restore power without the need for manual intervention. 4. Auto Vacuum Circuit recloser  it enhances safety by reducing the risk of electrical fires and accidents caused by prolonged power outages.. 5. Lastly,  the Auto Vacuum Circuit recloser can save costs in the long run by minimizing the need for manual intervention and reducing maintenance expenses. Technical Parameters USAGE USAGE: ENVIRONMENTAL CONDITION 1. Altitude: ≤ 3000m, If the altitude is higher than 3000m, the rated insulation level shall be corrected accordingly. 2. Ambient temperature: -30oC ~ +65oC 3. Wind Speed: 34m/s 4. Wind pressure: 700Pa 5. Pollution level: IV level 6. Icing thickness: Not more than 10mm 7. Storage Temperature: -40oC ~ +85oC Outline and Dimension
